Statistics of station Seifhennersdorf

Here you can find statistics of the TOA lightning detection station Seifhennersdorf.

General statistics of the last hour

  • Station active: yes
  • Last update: 2,311,971.5 minutes ago
  • Last detected stroke: 2020-08-03 09:50:41
  • Strokes: 18
  • Signals: 74
  • Locating ratio: 24.3%
  • Stroke ratio: 0.7% (Map)
  • Strokes station min participants: 0 (0.0%)

GPS

Some information about the GPS receiver, which is used for receiving the exact time an position. If known, the antenna bearings are also displayed (red, green).

  • Last position: 50.946577° / 14.609928°
  • Last time without GPS: 2018-08-25 04:20:19

Stroke count

Here you can see the whole stroke count per hours detected by the lightning network, the count of detected strokes/h of the station Seifhennersdorf and the mean stroke count for all stations

Graphs: Stroke statistics

Signal count

The count of received signals per hour of the station Seifhennersdorf and also mean value of all stations.

Graphs: Signal statistics

Ratios

Stroke and locating ratios are important parameters for the correct adjustment of the station. Calculations:
locating ratio = (detected strokes of the station) / (signals of the station)
stroke ratio = (detected strokes of the station) / (network stroke count)

Graphs: Locating and stroke ratios

Stroke ratio by distance

Overview about the own locating ratio over distance from stations. Whole stroke count over distance is also visible.

Graphs: Stroke ratio by distance

Stroke ratio by bearing

Own locating ratio over the geographic direction. For better comparision, there is also the whole stroke count visible.

Graphs: Stroke ratio by bearing

Antenna bearing

The bearing of the antennas can be detected automatically by MyLightningDetection. This is useful for determining the polarity of a stroke (very experimental!).

  • Bearing antenna 1: 9° - 189° (N-S)
  • Bearing antenne 2: 99° - 279° (E-W)
